Features
- High-performance powered loudspeaker system
- Patented JBL 2409H, 1-inch (25mm) compression driver and High-Definition Imaging dispersion horn
- JBL JW200P-4, 8-inch (200mm) Pure-pulp Black Paper Cone Woofers with Cast-frames
- 600-Watt RMS Total System Power with 24-bit/192kHz high-resolution DAC o (300-watts each speaker / 250-watts to each woofer and 50-watts to each compression driver)
- Google Chromecast Built-in, Apple AirPlay 2, and Bluetooth wireless audio
- USB and optical digital inputs plus XLR / ¼-inch TRS and 3.5mm analog inputs
- Incorporates MQA technology which enables playback of MQA audio files and streams, delivering the sound of the original master recording.
- ROON Ready
- Available in Natural Walnut or Black Walnut furnituregrade wood veneer finish options
- Wireless remote included and MusicLife app control available
Specifications
- Type: Bass-reflex Loudspeaker System with Built-in Amplification, DSP, and Wireless Connectivity
- Low Frequency Drivers: JW200P-4, 8-inch (200mm) Pure-pulp Black Paper Cone Woofers with Cast-frames
- High Frequency Drivers: 2409H, 1-inch (25mm) Annular Ring, Teonex® Diaphragm Compression Drivers with Advanced HDI™ Geometry Horns
- Amplifier Power: 600W Class D System Power 300W RMS per Speaker (50W per HF Compression Driver 250W per LF Woofer)
- Audio Resolution: Up to 24-bit, 192 kHz (Digital Link connection between spks) Up to 24-bit, 96 kHz (Wireless connection between spks)
- Frequency Response: 28 Hz - 25 kHz (-6 dB)
- Crossover Frequency 1,675 Hz
- Dispersion 90° Horizontal x 60° Vertical (2kHz to 15kHz) Sound Controls: Front Panel: Volume /- and Source Selection Bluetooth Remote Boundary Compensation (Flat / -3dB)
- Wireless Inputs: WiFi streaming, Bluetooth 5.3
- Wired Inputs: Analog: XLR/¼" Combo and 3.5mm stereo Digital: Asynchronous USB-B and Toslink/Optical Supported Digital Audio Sample Rates (PCM 2CH) Streaming & Local Media: 32kHz/44.1kHz/48kHz/88.2kHz/96kHz/176.4kHz/192kHz SPDIF: Up to 192kHz USB-B: PCM 2-channel, up to 192kHz Bluetooth: Up to 48kHz, aptX Adaptive up to 96kHz
- Music Formats Supported (Local Media) AAC / AIFF / ALAC / DSD64 (to PCM) / FLAC / MP3 / MP4 / MQA / OGG / WAV / WMA
- Subwoofer Output: Autosensing w/ Auto-engage of 80Hz High Pass Filter
- Remote Control Type: BTLE Wireless
- Bluetooth Audio Version 5.3 Profiles: SPP (Serial Port Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (Audio/Vido Remote Control Profile)
- Enclosure: Bass-reflex Design with Dual Front-facing Ports ¾" MDF Finished in Satin Walnut or Black Walnut Furniture-Grade Wood Veneer
- Grille: Dark Blue (with Walnut Cabinet) or Black (with Black Cabinet) Acoustically Transparent Cloth Grille
- Net Speaker Dimensions with grille: 20.3” H x12.6” W x 12.7” D (515.5mm x 320mm x 322.4mm)
- Net Speaker Weight: Primary: 34.5 lbs (15.7kg) Secondary: 34.3 lbs (15.6kg)
- Shipping Units of Measure: System Pairs
- Gross Shipping Dimensions: 25.59” H x 30.31” W x 16.46” D (650mm x770mm x 418mm)
- Gross Shipping Weight: 79.4 lbs (36.1 kg)
- AC Input Voltage: 100 - 240 VAC ( /-10%), 50/60Hz
